Product Detail
Low Pressure Switch PS-LA15
The Low Pressure Switch PS-LA15 offers the same proven compression spring and
precision snap action electrical switch as the other popular and widely used pressure switches.
The Low Pressure Switch PS-LA15 is designed specifically to variable applications with
wide adjusting set point from 0.05MPa to 0.6MPa, as well as to hold tight set point
tolerances throughout a wide temperature range.
| SPDT, SPST electrical loads: | 5A @ 125/250 VAC |
| 10A @ 125/250 VAC | |
| 16A @ 125/250 VAC | |
| Switching circuits | SPDT, SPST-NO, SPST-NC |
| Electrical terminals: | #187 (3/16”) 4.8x0.5 mm quick connect |
| #250 (1/4”) 6.3x0.8 mm quick connect | |
| Set points Tolerance: | +/-5% ~ +/-10% of set point. |
| Overpressure rating: | 1.2MPa |
| Ambient temperature range | -25 + 85℃ |
| Sampling line connector: | 1/8” NPT or 1/4” NPT male connectors; other,other types of connector on customer demands. |
| Sampling Medium | Air, water or compatible fluids |
| Dimensions | For typical dimensions |
| Mounting Orientation |
Diaphragm must be vertical (Horizontal optional). |
| Materials: | Diaphragm: Post-cured silicone, RTI>150 deg C. |
| Pressure housing: Thermo-plastics with RTI>130 | |
| Snap action switch housing: Thermo-plastics with RTI>120 deg C, UL94 V-0. | |
| Product Life: | Mechanical: 200,000 cycles. |
| Electrical: 100,000 cycles. | |
| Approvals | CE, CQC |
If you need Low Pressure Switch PS-LA15, please feel free to contact us for price by submitting "more information" as below !
