Cable Float Switch LS-CF05



Cable Float Switch LS-CF05 uses one-step shaping injection molding with substantial
structure, cheap price and long lifetime. It has very good control effect for long distance,
multiple level control, submerged pump or liquid with grain or block. Certainly it is also
useful for normal liquid. It uses Micro Switch to make connection output. Connection point
capacity 10A/250VAC can start the motor equipment directly. It can be regulated freely
and easy to operate, convenient to install, safe and reliable, without maintenance, non-toxic
and environment friendly. It can resist sewage so that widely used in pool in resident,
factories and mines ect., and ponds, barrel, manger and pot with oil, acid and alkali as well
as the vessel with high viscosity and suspended substance.



Product Name Cable Float Switch LS-CF05
Electrical rate 250VAC, 10(4)A/16(4)A
Contact Mode SPDT, NO, NC
Working Temperature 0~60℃(PVC cable), 0~80℃(Rubber cable)
Protection grade IP 68
Float Material PP/PVC
Application water, sewage, acid-bases liquid
Working Pressure ±0.5Mpa
Cable Material: PVC/rubber
Length:  4m(standard); length could be customized
Conductor size:  3x0.5mm2 (standard)
                           3x0.75mm2
                           3x1.0 mm2
Installation Method throw-in type vertical installation
